EchoLife HG520 Home Gateway
Quick Guide
Welcome to purchase the EchoLife HG520 Home Gateway device(the
HG520 for short). With your HG520, you can access the Internet using
your high-speed ADSL AP router.
This manual shows how to install your HG520.
Getting to Know
The HG520 is a kind of Internal ADSL AP router for high speed
internet access.It has a 10/100Base-T Ethernet router to provide
Internet connectivity to all computers on your LAN. It also support
IEEE 802.11g 54Mbit/s Access Point.
Rear Panel
The rear panel provides ports for the HG520 to receive/send data and
get power supply..
Label Function
SW Power Button. Switches the device on and off
DC-IN Connects to the power adapter cable
RST Press the reset button for 2 seconds the HG520
will be restarted (rebooted). To reset to default
settings, turn off the device first. Hold the Reset
button and then turn on the device; wait for 5~8
seconds and then release the button. Resets
device’s configuration to factory default
LAN1-4 RJ-45 connector: connects the device to your
computer's Ethernet port, or to the uplink port on
your LAN's hub, using the cable provided.
DSL RJ-11 connector: connects the device to a
telephone jack using the supplied cable
Front Panel
The front panel provides LED indicators to indicate the device status.
Label Color Function
PWR Green On: The device is powered on
Off: The device is powered off
