User Manual
EchoLife HG520 Home Gateway
Chapter 2 Hardware Description
Huawei Technologies Proprietary
6
Caution:
Before cable connection, turn off your computer(s), LAN hub/switch (if
applicable), and the HG520.
I.
Connect the ADSL cable
Connect one end of the phone cable to the RJ-11 connector on
the rear panel of HG520. Connect the other end to the ADSL outlet
provided by your service provider (normally MODEM port of the
attached splitter).
II.
Connect the Ethernet cable
Connect one end of the Ethernet cable to the one of the four
RJ-45 connectors on the rear panel of HG520 , connect the other end
to your computer’s network adaptor (NIC). If you are connecting a
LAN to HG520, attach one end of the Ethernet cable to a regular hub
port and the other end to the LAN port on HG520.
III.
Attach the power connector
Connect the AC power adapter to the power connector on HG520
and plug in the adapter to a wall outlet or power extension.
