Huawei EchoLife HG8045A User Manual

EchoLife HG8245A/HG8245H/HG8240A/HG8045A
GPON Terminal
Product Description
1 Introduction
Issue 01 (2013-08-08)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
Port/Button
Function
POWER
Indicates the power port, used to connect to the power
adapter or backup battery unit.
USB
Indicates USB host port, used to connect to USB storage
devices.
TEL1–TEL2
Indicates VoIP telephone ports (RJ-11), used to connecting to
the ports on telephone sets.
LAN1–LAN4
Indicates auto-sensing 10/100/1000M Base-T Ethernet ports
(RJ-45), used to connect to PCs or IP set-top boxes (STBs).
Figure 1-4 Ports and buttons on the side cover of the HG8245H
Table 1-2 Description of ports and buttons on the side cover of the HG8245H
Port/Button
Function
Reset
Indicates the reset button. Press the button for a short time to
reset the device; press the button for a long time (longer than
10s) to restore the device to the default settings and reset the
device.
WLAN
Indicates the WLAN button, used to enable or disable the
WLAN function.
WPS
Indicates the WLAN protected setup.
Figure 1-5 shows optical ports on the HG8245H.

Huawei EchoLife HG8045A Specifications

General

Brand	Huawei
Model	EchoLife HG8045A
Category	Network Router
Language	English
