Huawei EchoLife HG8045A User Manual

EchoLife HG8245A/HG8245H/HG8240A/HG8045A
GPON Terminal
Product Description
1 Introduction
Issue 01 (2013-08-08)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9
No.
LED Status
Description
PON
LOS
second)
second)
is a rogue ONT.
6
Blinks quickly
(twice per
second)
Blinks slowly
(once two
seconds)
The Rx optical power of the ONT
does not within the range (–27
dBm to –8 dBm) of the Rx
sensitivity.
7
Blinks slowly
(once two
seconds)
Blinks slowly
(once two
seconds)
The hardware is faulty.
Device parameters
The device parameters include the ONT's size, weight, operating environment, and power
parameters and equipment power consumption.
Table 1-6 HG8245H device parameters
Parameter
Specifications
Dimensions (length x width x height)
176 mm x 138.5 mm x 28 mm (without an
external antenna)
Weight
About 500 g
Working environment
Operating temperature: 0ºC to +40ºC
Environment humidity: 5% RH to 95% RH
(non-condensing)
Pressure environment: 86 kPa to 106 kPa
Altitude: 2000 m
Power specifications
Power adapter input: 100 V AC to 240 V
AC, 50 Hz to 60 Hz
System power supply: 11 V DC to 14 V
DC, 2 A
Power consumption

Static power consumption: 5 W

Maximum power consumption: 15.5 W
1.4.2 HG8045A
Introduced the appearance, interfaces, LEDs and device parameters of the HG8045A.
