EchoLife HG8245A/HG8245H/HG8240A/HG8045A
GPON Terminal
Product Description
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Appearance
Figure 1-7 Appearance of the HG8045A
Port/Button
Figure 1-8 and Figure 1-9 show the ports on the rear panel and side panel of the HG8045A
respectively.
Figure 1-8 Ports and buttons on the rear panel of the HG8045A
Table 1-7 Description of ports and buttons on the rear panel of the HG8045A
Indicates the power button. It is used to power on or power
off the device.
Indicates the power port, used to connect to the power
adapter or backup battery unit.
Indicates auto-sensing 10/100M Base-T Ethernet ports
(RJ-45), used to connect to PCs or IP set-top boxes (STBs).
