Huawei EchoLife HG8045A User Manual

EchoLife HG8245A/HG8245H/HG8240A/HG8045A
GPON Terminal
Product Description
1 Introduction
Issue 01 (2013-08-08)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7
LEDs
Figure 1-6 LEDs on the HG8245H
Table 1-4 Indications of the LEDs on the HG8245H
LED
Description
Status
Description
POWER
Power supply
LED
Always on
The device is powered on.
Off
The power supply is cut off.
PON
Authentication
LED
See Table 1-5.
LOS
Connection
LED
See Table 1-5.
LAN1–LAN4
Ethernet port
LED
Always on
The Ethernet connection is in the
normal state.
Blinking
Data is being transmitted on the
Ethernet port.
Off
The Ethernet connection is not set
up.
TEL1–TEL2
Voice
telephone port
Always on
The HG8245H is registered with
the softswitch but no service

Huawei EchoLife HG8045A Specifications

General

Brand	Huawei
Model	EchoLife HG8045A
Category	Network Router
Language	English
