Huawei EchoLife HG8045A User Manual

EchoLife HG8245A/HG8245H/HG8240A/HG8045A
GPON Terminal
Product Description
1 Introduction
Issue 01 (2013-08-08)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
22
Table 1-21 Description of optical ports on the HG8245A
Port/Button
Function
OPTICAL
Indicates an optical port. The optical port is equipped with a
rubber plug and is connected to an optical fiber for upstream
transmission.
The type of the optical connector connected to the OPTICAL
port is SC/APC.
LEDs
Figure 1-21 LEDs on the HG8245A
Table 1-22 Indications of the LEDs on the HG8245A
LED
Description
Status
Description
POWER
Power supply
LED
Green: always
on
The device is powered on.
Orange: always
on
The power supply is cut off.
PON
Authentication
See Table 1-23.
