Page #3 background imageLoading...
Page #3 background image
3
Indicator Status Description
WLAN Green on 2.4G Wi-Fi
®
connection is set up.
5G Wi-Fi connection is set up.
Both 2.4G & 5G Wi-Fi are set up.
The HG633 is connected to a wireless client
using the Wi-Fi Protected Setup (WPS)
function.
Green
Blinking (0.5
Hz)
The WLAN connection is set up, and data is
being transmitted.
The WPS is in progress or error status.
Green
Blinking (2
Hz)
The WLAN connection is set up, and data is
being transmitted.
Off Both 2.4G & 5G Wi-Fi are disabled.
The HG633 is powered off.
LAN Green on The LAN port is connected to an Ethernet device
(such as a computer) with a network cable, but
no data is being transmitted.
Green
Blinking
The LAN port is connected to an Ethernet device
with a network cable, and data is being
transmitted.
Off No connection is set up on the port.
The HG633 is powered off.
USB Green on A portable storage device is connected to the
USB port.
No data is being transmitted.
Blinking Data is being transmitted on the USB port.
Off No connection is set up on the port.
The HG633 is powered off.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Huawei HG633 and is the answer not in the manual?

Huawei HG633 Specifications

General IconGeneral
TypeGateway
Wireless Standards802.11b/g/n
Frequency Band2.4 GHz
Wireless SpeedUp to 300 Mbps
Ethernet Ports4 x 10/100 Mbps
ADSL/VDSL Port1 x RJ11
USB Ports1 x USB 2.0
FirewallYes
SecurityWPA, WPA2
