Huawei HG658 Quick Start

2
3 Accessing the Internet
To set up network access for the HG658 and your computer:
Step 1
Open a web browser on your computer. Enter
http://192.168.1.1
in the address box,
and then press
Enter
.
Step 2
On the login page, enter the user name (
user
by default) and password (
HuaweiUser
by default).
Step 3
Click
Login
.
After the system verifies your account, the web-based configuration utility is
displayed.
The first time you log in to the web-based configuration utility, a setup wizard
is displayed. To skip the wizard and go immediately to the HG658
configuration page, click Advance.
Step 4
In the displayed setup wizard, click
Next
.
If you have configured the HG658 before and you log in to the web-based
configuration utility, the setup wizard page will not be displayed. However,
you can still click Setup Wizard in the upper right corner to display the
setup wizard page.
Step 5
Set
WAN device
based on your network type, and then enter the user name and
password that are provided by your Internet Service Provider (ISP) in the
User name
and
Password
text boxes.
Step 6
Click
Next
.
Step 7
Set
SSID
and
WPA pre-shared key
, and then click
Next
.
Check the label on the HG658's rear panel for SSID and WPA pre-shared
key.
Step 8
Click
Submit
.
After you complete the preceding settings, you can start surfing the Internet.
You need to perform the preceding operations on a computer only once. The next time you
power on your computer, you can start surfing the Internet without any further configurations.

Huawei HG658 Specifications

General

Frequency Band	2.4 GHz
Wireless Standard	802.11b/g/n
LAN Ports	4
WAN Port	1
USB Port	1
Security	WEP, WPA, WPA2
Type	ADSL2+
