Huawei HG659 User Manual

3
Internet
Steady green
The HG659 is connected to the Internet in router
mode, but no data is being transmitted.
Blinking green
The HG659 is connected to the Internet in router
mode, and data is being transmitted.
Off
> The HG659 is in router mode, but not connected to
the Internet.
> The HG659 is in bridge mode.
WLAN
Steady green
The HG659 has WLAN enabled, but is not transmitting
data.
Fast Blinking
(2Hz)
The HG659 has WLAN enabled, and data is being
transmitted.
Slow Flashing
(1Hz)
The HG659 is attempting to connect to a wireless
client over the WLAN using the WPS function.
This process lasts for no longer than 120 seconds.
Off WLAN is disabled.
VoIP
Steady green
The HG659 is registered with a SIP server, but no
data is being transmitted.
Blinking green
The HG659 is registered with a SIP server, and data is
being transmitted.
Off The HG659 is not registered with a SIP server.
LAN1 ～ LAN4
Steady green
The LAN port is connected to an Ethernet device
(such as a computer) with a network cable, but no
data is being transmitted.
Blinking green
The LAN port is connected to an Ethernet device with
a network cable, and data is being transmitted.
Off The LAN port is not connected to any Ethernet device.
USB
Steady green
The USB port is connected to an USB device, but no
data is being transmitted.
Blinking green
The USB port is connected to an USB device, and
data is being transmitted.
Off The HG659 is not connected to any USB device.
Indicator Status Description

Huawei HG659 Specifications

General

LAN Ports	4 x Gigabit Ethernet
WAN Ports	1 x Gigabit Ethernet
VoIP	Yes
Firewall	Yes
Wireless Standard	802.11b/g/n
Frequency Band	2.4 GHz
USB Ports	1
DSL Support	VDSL2/ADSL2+
Wi-Fi Speed	Up to 1.3 Gbps
DSL Standards	ITU G.993.2, ITU G.992.5
