Description
Band
Test Value
Units
Power (Unit: dBm)
Band 41
197
mA
0 dBm Tx Power
237
10 dBm Tx Power
362
23 dBm Tx Power
TD-SCDMA
Band 34
87
mA
0 dBm Tx Power
97
10 dBm Tx Power
136
23 dBm Tx Power
Band 39
87
mA
0 dBm Tx Power
96
10 dBm Tx Power
127
23 dBm Tx Power
Table 5-8 Averaged Data Transmission DC power consumption of ME909s-120
(WCDMA/HSDPA/LTE)
Description
Band
Test Value
(Unit: mA)
Power (Unit: dBm)
WCDMA
Band 1
(IMT 2100)
176
0 dBm Tx Power
213
10 dBm Tx Power
645
23.5 dBm Tx Power
Band 2
(PCS 1900)
175
0 dBm Tx Power
201
10 dBm Tx Power
637
23.5 dBm Tx Power
Band 5
(850 MHz)
168
0 dBm Tx Power
189
10 dBm Tx Power
514
23.5 dBm Tx Power
Band 8
(900 MHz)
174
0 dBm Tx Power
208
10 dBm Tx Power
587
23.5 dBm Tx Power
HSDPA
Band 1
(IMT2100)
186
0 dBm Tx Power
225
10 dBm Tx Power
656
23.5 dBm Tx Power
