Distribution of Switch Ports
Distribution of network ports on switch 1
On a switch, network ports are numbered from bottom to top and then from left to right.
Network cables are clearly labeled before delivery. The following tables describe distribution of network ports on
switches to help you quickly complete network cable connections.
Device Port Switch port Number
Switch port Number Device Port
- 1 2 -
- 3 4 -
- 5 6 -
- 7 8 -
MDS1 NIC1 9 10 MDS1 NIC2
MDS2 NIC1 11 12 MDS2 NIC2
OSN1 NIC1 13 14 OSN1 NIC2
OSN2 NIC1 15 16 OSN2 NIC2
- 17 18 -
SD-Node-1 IPMI 19 20 C-Node1 IPMI
C-Node-3 IPMI 21 22 -
MDS-1 IPMI 23 24 OSN-1 IPMI
SD-Node-1 Slot0-B 25 26 SD-Node-2 Slot-0-B
C-Node-1 Slot2-B 27 28 C-Node-2 Slot-2-B
C-Node-3 Slot2-B 29 30 -
- 31 32 -
- 33 34 -
SD-Node-1 Slot0-A 35 36 SD-Node-2 Slot-0-A
C-Node-1 Slot2-A 37 38 C-Node-2 Slot-2-A
C-Node-3 Slot2-A 39 40 -
- 41 42 -
- 43 44 -
- 45 46 -
- 47 48 -
b
Distribution of network ports on switch 2
Device Port Switch port Number
Switch port Number Device Port
- 1 2 -
- 3 4 -
- 5 6 -
- 7 8 -
MDS1 Slot0-A 9 10 MDS1 Slot3-A
MDS2 Slot0-A 11 12 MDS2 Slot3-A
OSN1 Slot1-A 13 14 OSN1 Slot2-A
OSN2 Slot1-A 15 16 OSN2 Slot2-A
- 17 18 -
SD-Node-2 IPMI 19 20 C-Node2 IPMI
- 21 22 -
MDS-2 IPMI 23 24 OSN-2 IPMI
SD-Node-1 Slot-3-B 25 26 SD-Node-2 Slot3-B
C-Node-1 Slot3-B 27 28 C-Node-2 Slot-3-B
C-Node-3 Slot3-B 29 30 -
- 31 32 -
- 33 34 -
SD-Node-1 Slot3-A 35 36 SD-Node-2 Slot-3-A
C-Node-1 Slot3-A 37 38 C-Node-2 Slot-3-A
C-Node-3 Slot3-A 39 40 -
- 41 42 -
- 43 44 -
- 45 46 -
- 47 48 -
