Huawei OceanStor V3 Series - Connecting Cables; A Generic View of Cable Connections on the Controller Enclosure

3a
A generic view of cable connections on the controller enclosure
3 Connecting Cables
13
Application
server
Controller
enclosure
Disk
enclosure
Maintenance
terminal
External
power
External
power
When the storage system has two or more controller enclosures configured, connect cables following
instructions in the OceanStor 2000, 5000, and 6000 V3 Series V300R006 Installation Guide.
3c, 3d, 3e, and 3f in the following figure indicate the section numbers in this document.
The following figure uses AC power modules as an example to describe cable connection.
