Quidway
®
S5100-EI Series Intelligent and Resilient Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://datacomm.huawei.com
4
Attribute S5100-EI
Management/ Maintenance
System
Configuration
and
Management
Support CLI (Command Line Interface) configuration mode
Support Configuration via the console port
Support Local/Remote configuration via Telnet
Support Remote configuration via modem dial-up
Support System configuration with SNMP v1, 2 and 3
Support HGMP V2
Support RMON (Remote Monitoring) v1, 1/2/3/9 groups of MIBs
Web-based network management
System
Maintenance
and debugging
Detailed alarm/debug information output
Support Ping and Tracert
Support remote maintenance via Telnet Modems and SSH
Support NQA
Support System log
Hierarchical alarm management and alarm filtering
Support DLDP (Device Link Detection Protocol)
Loopback detection on ports
Support VCT(Virtual Cable Test)
Information
center
Exporting switch synchronization information
Setting the format of time stamps to be sent to log hosts
Description S5124P-EI S5148P-EI S5126C-EI S5150C-EI
Outline
dimension
43.6 × 260 × 440 mm (1.72 × 10.2 ×
17.3 in.)
43.6 × 300 × 440 mm (1.72 × 11.8 × 17.3
in.)
Weight
< 4 kg (< 8.8 lb) 4 kg (8.8 lb) 4 kg (8.8 lb) < 5 kg (< 11 lb)
Power supply
S5100-EI series support both AC and DC power inputs
AC input:
Rated voltage range: 100 VAC to 240 VAC, 50 Hz or 60 Hz
Max voltage range: 90 VAC to 264 VAC, 47 Hz or 63 Hz
DC input:
Rated voltage range: -48 V to -60 V
Max voltage range: -36 V to -72V
Maximum power
consumption
39 W 78 W 54 W 97 W
MTBF (Years)
22.0 21.1 13.3 12.1
Noise parameter
46.7dBA 50.2dBA 50.1dBA 51.5dBA
Environment
Operation temperature: 0°C ~ 45°C
Operating humidity: 5% to 85% non-condensing
Relative humidity: 10% ~ 90%, non-condensing
