R230D&R240D
Product Description 4 Technical Specifications
Issue 02 (2015-10-31) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
16
Table 4-2 Basic specifications of the R240D
Item Description
Technical specifications Dimensions outside the wall
(L × W × H)
140mm×86mm×25mm
Dimensions inside the wall
(L × W × H)
51.5mm×63.5mm×16.5mm
Weight 0.2 kg
System memory
128 MB DDR2
32 MB Flash
Power specifications Power input
12 V±10%
PoE power: in
compliance with IEEE
802.3af/at
Maximum power
consumption
8.7 W
NOTE
The actual maximum power
consumption depends on local
laws and regulations.
Environment specifications Operating temperature and
altitude
-60 m to +1800 m: 0°C to
+40°C
1800 m to 5000 m:
Temperature decreases by
1°C every time the altitude
increases 300 m.
Storage temperature -40°C to +70°C
Operating humidity 5% to 95%
(non-condensing)
IP rating IP20
Atmospheric pressure 70 kPa to 106 kPa
4.2 Radio Specifications (R230D)
Table 4-3 Radio specifications
Item Description
Antenna
type
Built-in antenna
Antenna
gain
2.4 GHz: 3 dBi
5 GHz: 4 dBi
