Huawei S1720-52GWR-4X

Item Description
Noise under
normal
temperature
(27°C, sound
power)
< 48.3 dB(A)
Relative humidity 5% to 95%, noncondensing
Operating
altitude
0-5000 m (0-16404 ft.)
Certication ● EMC certication
● Safety certication
● Manufacturing certication
Part number ● S1720-52GWR-PWR-4X: 98010624
● S1720-52GWR-PWR-4X-E: 98010751
5.2.19 S1720-28GWR-PWR-4TP/S1720-28GWR-PWR-4TP-E
This section uses S1720-28GWR-PWR-4TP as an example. S1720-28GWR-
PWR-4TP-E has the same hardware structure as S1720-28GWR-PWR-4TP.
Appearance
Figure 5-29 shows the appearance of an S1720-28GWR-PWR-4TP.
Figure 5-29 Appearance of an S1720-28GWR-PWR-4TP
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
282725
1G1G
PoE 1-8
MODE
HUAWEI
PoE
SPED
STAT
SYS
PWR
26
1G
S1720-28GWR-PWR-4TP
~100-240V;50/60Hz; 3A
RST
2
3
9
4
5
6 7 8
1
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 113
