Item Description
Extinction ratio (dB) 3.5
Operating temperature -40°C to +85°C (-40°F to +185°F)
Part number 02311BJJ
NO TE
This module can only be used on a switch running V200R008C00 or a later version. A
switch running an earlier version may fail to obtain information about this module.
9.6.4 OSX010000
Table 9-33 Technical
Specications
Item Description
Transceiver form factor SFP+
Transmission speed 10GE
Center wavelength
(nm)
1310
Standards compliance 10GBASE-LR
Connector type LC
Applicable cable and
maximum transmission
distance
Single-mode ber: 10 km
Transmit power (dBm) -8.2 to +0.5
Maximum receiver
sensitivity (dBm)
-12.6
Overload power (dBm) 0.5
Extinction ratio (dB) 3.5
Operating temperature 0°C to 70°C (32°F to 158°F)
Part number 02318170
9.6.5 OSX040N01
