Huawei S1720 Series User Manual

Display Mode Status Description
Blinking green and orange
alternately
The interface cannot provide
power to PDs. The possible
reasons including:
l The power of a connected PD
exceeds the interface's
powering capability or upper
power supply threshold.
l The power provided by the
switch has reached the
powering capability of the
switch.
l The PoE power function is not
enabled on the interface in
manual power-management
mode.
Stack
Off The stack ID of the member
switch is not the number of the
interface in the off state.
Green The device is a not a command
switch:
l If the indicator of an interface
is steady on, the number of this
interface is the stack ID of the
device.
l If the first nine interface
indicators of the device are
steady on, the stack ID of the
device is 0.
Blinking green
The device is a command switch:
l If the indicator of an interface
blinks, the number of this
interface is the stack ID of the
device.
l If the first nine interface
indicators of the device blink,
the stack ID of the device is 0.
2.6 S6700 Indicator Description
This section describes the indicators on the S6700 front panel.
Indicators of S6700 Switch
In the following description, the indicators of S6700-24-EI are described as an example.
S3700&S5700&S6700 Series Ethernet Switches
Quick Start 2 Product Hardware Introduction
Issue 02 (2012-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
42

Huawei S1720 Series Specifications

General

Operating Humidity	5% to 95% (non-condensing)
Uplink Ports	4 x GE combo ports
VLANs	4094
Power Supply	AC 100-240V, 50/60Hz
Layer 2 Features	VLAN
Layer 3 Features	Static routing
Management	SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to +70°C
Dimensions (W x D x H)	442 mm x 220 mm x 43.6 mm
