Figure 5-2 Configuring the interface for connection
Step 4 Set communication parameters.
When the COM1 Properties dialog box is displayed as shown in Figure 5-3, specify the
parameters listed in Table 5-1.
NOTE
In other Windows operating systems, bits per second may be described as baud rate and data stream control
may be described as traffic control.
S3700&S5700&S6700 Series Ethernet Switches
Quick Start 5 Logging in to the Device
Issue 02 (2012-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
56

Huawei S1720 Series Specifications

General

Operating Humidity	5% to 95% (non-condensing)
Uplink Ports	4 x GE combo ports
VLANs	4094
Power Supply	AC 100-240V, 50/60Hz
Layer 2 Features	VLAN
Layer 3 Features	Static routing
Management	SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to +70°C
Dimensions (W x D x H)	442 mm x 220 mm x 43.6 mm
