1. Launch the Internet Explorer on the computer. Enter http://192.168.1.1 in
the address bar and press Enter.
2. In the displayed dialog box, enter the user name and the password, and then
click OK.
By default, both the user name and the password are admin. After the password is
verified, you can access the Web configuration page.
Step 2
Enable the embedded dial-up function.
1. In the navigation tree on the left of the Web Configurator, choose Basic >
WAN Setting.
2. Select a PVC number, such as 1, from the PVC drop-down combo box.
3. Enter the VPI and VCI parameters that are provided by the network operator
in the VPI and VCI text boxes.
4. Select Yes from the Active drop-down combo box and select Routing from
the Mode drop-down combo box.
5. Enter the user name and password that are provided by the network
operator in the Username and Password text boxes , keep the default settings
of other parameters.
6. Click Submit to save the settings.
After you complete the preceding settings, you can surf the Internet.
You need to perform the preceding operations on a computer only once. The next time
when you power on the computer, you can surf the Internet without performing any
configuration.
4 Indicators
Indicator Status Description
On The MT882a is powered on. POWER
Off The MT882a is powered off.
Blinking The MT882a is being activated.
On The MT882a is activated.
ADSL
Off The MT882a is powered off.
Blinking
Data is being transmitted through the Ethernet
interface.
On The Ethernet connection is established.
LAN
Off The Ethernet connection is not established.
5
