3 Product Specifications
3.1 Hardware Specifications
Body dimensions
(H x W x D)
73 mm * 73mm * 202mm
Note: Actual product dimensions will vary depending on the
configuration and manufacturing process.
Device: 680 g
Packaged device: 850 g
(Note: Actual product weight will vary depending on the
configuration and manufacturing process.)
Cortex-M33 Star1 dual-core MCU: 300 MHz
Cortex-A7 dual-core: 1 GHz
1 x 20 W (full-range trumpet) + 1 x 10 W (tweeter trumpet)
1x50 mm x 75 mm full-range racetrack trumpet unit + 1x19 mm
tweeter trumpet + 2 x passive radiator (PR) unit
3 microphones for sound pickup (switches to 2-microphone
sound pickup when the gravity sensor detects that the speaker
is horizontally placed)
5 V/2 A, 9 V/2 A, or 10 V/4 A
