5
3. Install the SUN2000 onto the mounting
bracket.
4. Tighten the screws on both sides of the
SUN2000.
1. Install the two mounting brackets together.
2. Align the mounting holes and install the
new mounting bracket.
Connect cables in accordance with local installation laws and regulations.
Before connecting cables, ensure that the DC switch on the SUN2000 and all the switches
connected to the SUN2000 are set to OFF. Otherwise, the high voltage of the SUN2000 may
result in electric shocks.
Do not connect the neutral wire to the enclosure as a PE cable. Otherwise, electric shocks may
occur.
The mounting holes of the engineering mounting kits must be identical to the original one. The
mounting holes can be directly aligned with those on the support. However, if you install the
mounting bracket on a wall, you need to make new holes.
3
Connecting a PE Cable
