Huawei UPS2000-A-1KTTS

Optional
Component
Model Function Remarks
External charger CHG-36V15A-01B Connects the battery pack
or rack to the mains and
charges the batteries or
battery pack.
Applicable to the 1
kVA UPS with long
backup time.
CHG-72V12A-01B Applicable to the 2
kVA UPS with long
backup time.
CHG-96V10A-01B Applicable to the 3
kVA UPS with long
backup time.
High-voltage
protector
OVCD-230V16A-01B The OVCD is connected
between the mains and
the UPS input. If the
mains voltage is
abnormally high, the
OVCD actively disconnects
the L wire between the
mains input and UPS to
prevent the abnormally
high voltage from owing
into the UPS and
damaging the UPS. In
addition, the OVCD
provides extra input surge
voltage absorbing
capability and input
ltering capability.
-
UPS2000-A-(1 kVA-3 kVA)
User Manual 2 Product Overview
Issue 17 (2024-01-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 23
