UPS2000-A-(6 kVA-10 kVA)
User Manual
Issue
05
Date
2019-12-19
HUAWEI TECHNOLOGIES CO., LTD.

Table of Contents

Other manuals for Huawei UPS2000-A-6KTTS-S

Preview: Quick Guide
Quick Guide21 pages

Questions and Answers

  • L
    Loretta StoneAug 16, 2025
    What to do if my Huawei UPS2000-A-6KTTS-S UPS battery discharge time is too short?
    • B
      Brandon BlairAug 16, 2025
      If the battery discharge time is much less than the standard time, it could be that the batteries are not fully charged. In this case, charge the batteries for more than 8 hours when the mains is normal. Alternatively, the battery performance may have deteriorated. Test the discharge time again, and if the issue persists, contact local Huawei technical support to replace the batteries.
  • G
    greenestevenAug 19, 2025
    Why is my Huawei UPS not starting when I press the power button?
    • B
      bgatesAug 19, 2025
      If the UPS does not start after you press the power button, it could be that the button was not pressed long enough. Press the button for more than 5 seconds until you hear a beep. Another possible cause is an overload. Disconnect all loads and restart the UPS.
  • B
    Barry ObrienAug 21, 2025
    What to do if my Huawei UPS2000-A-6KTTS-S is making abnormal noises or smells?
    • G
      gailbakerAug 22, 2025
      If abnormal noises or smells are generated in the UPS cabinet, it indicates that the UPS is faulty. Shut down the UPS immediately, cut off the input power supply, and contact local Huawei technical support.
  • B
    bennettadamAug 25, 2025
    What to do if the Huawei UPS battery discharge time is too short?
    • B
      bellanthonyAug 26, 2025
      If the Huawei UPS battery discharge time is significantly less than expected, it could be due to a couple of reasons. First, the batteries may not be fully charged; in this case, charge them for at least 8 hours with normal mains power, and then test the discharge time again. Second, the battery performance may have deteriorated, requiring you to contact local Huawei technical support to replace the batteries.
  • B
    bauermichaelAug 27, 2025
    What to do if my Huawei UPS doesn't start after pressing the power button?
    • C
      Cody BryantAug 27, 2025
      If your Huawei UPS fails to start after pressing the power button, try the following: First, press and hold the power button for more than 5 seconds until you hear a beep. If that doesn't work, disconnect all loads and then restart the UPS.
  • R
    Renee SmithAug 30, 2025
    Why is the Huawei UPS mains indicator off?
    • D
      Dennis LaneAug 30, 2025
      The mains indicator might be off because the mains voltage or frequency is outside of the UPS's acceptable input range. Use a multimeter to verify that the input voltage and frequency meet the specified requirements.
  • L
    Lucas HoltSep 1, 2025
    What to do if Huawei UPS is running on battery even when mains is normal?
    • J
      James MasonSep 1, 2025
      If your Huawei UPS is operating in battery mode despite normal mains power, there are a couple of things to check. First, ensure that the mains switch is turned on. Second, verify that the input power cable is securely connected.
  • T
    tracynguyenSep 4, 2025
    What to do if Huawei UPS has no output voltage?
    • J
      Jennifer JeffersonSep 5, 2025
      If the Huawei UPS reports no faults but has no output voltage, check that the output power cable is securely connected.
  • R
    Ryan PayneSep 7, 2025
    What to do if the Huawei UPS battery indicator is blinking yellow?
    • B
      Bryan RodriguezSep 8, 2025
      If the battery indicator on your Huawei UPS is blinking yellow, and the buzzer is beeping intermittently, it indicates insufficient battery capacity and that the UPS is shutting down. Immediately save any load data and power off any critical loads. Also, connect the UPS input terminals to a backup AC power supply.
  • J
    James DanielsSep 10, 2025
    How to troubleshoot a Huawei UPS with a blank LCD screen?
    • A
      Angela HuntSep 10, 2025
      If the mains switch is ON but the LCD on your Huawei UPS is blank and the system isn't performing self-tests, the issue might be related to the input power supply. Check that the input power cable is properly connected. Also, the input voltage might be out of range; use a multimeter to confirm that the UPS input voltage meets the required specifications.

Huawei UPS2000-A-6KTTS-S Specifications

General IconGeneral
ModelUPS2000-A-6KTTS-S
Rated Capacity6 kVA / 5.4 kW
Input Voltage220/230/240 VAC
Input Frequency Range40-70 Hz
Output Voltage220/230/240 VAC
Output Frequency50/60 Hz
Transfer Time0 ms
Form FactorTower
TopologyDouble Conversion Online
Input Voltage Range160-300 VAC
Battery TypeSealed Lead-Acid Maintenance-Free
Typical Backup Time5-30 minutes (depends on load)
Communication PortsRS232, USB
Operating Temperature0°C ~ 40°C
Operating Humidity0% ~ 95% (non-condensing)
