Battery pack 1
Battery pack 2
Battery pack 3 Battery pack 4
Battery pack 5 Battery pack 6
Battery pack 7
Battery pack 8
4
(Optional) Connecting Cables to Optional Cards
SNMP Card
For details about how to install the SNMP card, dry contact card, and Modbus card, see the
RMS-SNMP01A V100R001 Installation Guide
,
RMS-MODBUS01A User Manual
, and
RMS-
RELAY01A User Manual
.
Dry Contact Card
Temperature
and humidity
sensor
Ethernet
Customer
equipment
