Q6: How do I connect my router to the HUAWEI CPE to expand the Wi-Fi network?
You can connect your router in either of the following ways:
Wired connection
Place your router in a room with weak or no signal strength, then connect the WAN port of your router
to the LAN port of the HUAWEI CPE using an Ethernet cable.
Wireless connection (using the H button)
Step 1: Place the router within one meter of the HUAWEI CPE and connect the power supply.
within one meter
Step 2: When the indicator on the HUAWEI CPE starts to flash, press the H button on it. Wait until the
indicator on the router shows that the router is connected to the network.
Step 3: Place the router in a room with weak signal strength and connect the power supply.
The figure is for reference only.
Ensure that the HUAWEI CPE is connected to the Internet, and the router is new or restored to factory
settings.
Ensure that the HUAWEI CPE supports the HUAWEI HiLink function and CoAP protocol. Please consult
the distributor for details.
Ensure that the distance between your router and the HUAWEI CPE is less than 10 meters and there are
no more than one wall in between.
9

Other manuals for Huawei WIFI AX2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Huawei WIFI AX2 and is the answer not in the manual?

Huawei WIFI AX2 Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standardWi-Fi 6 (802.11ax)
WLAN data transfer rate (max)1201 Mbit/s
WLAN data transfer rate (first band)300 Mbit/s
Antennas quantity4
Internal memory128 MB
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Output current1 A
Power source typeAC, DC
Power consumption (typical)12 W
Security algorithmsSSID, WPA3
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95 %
Product typeTabletop router
Product colorWhite
Ethernet LAN (RJ-45) ports3
Mobile network generation-
Weight and Dimensions IconWeight and Dimensions
Depth163.5 mm
Width257.6 mm
Height29 mm
Weight216 g
