Huawei WIFI AX2 Quick Start Guide

Manage the router with our mobile app
Scan the QR code to download and install the HUAWEI AI Life App
on your mobile phone or tablet. You can use the app to manage
your router.
Indicator
Steady green
Connected to the network
Not connected to the network
• Loose cable or connect error. Check the cable.
• Broadband network error. Contact your broadband carrier.
Steady red
Flashing
The router has detected a pairable device.
When other HUAWEI devices (support HarmonyOS Connect) , the indicator
on the HUAWEI WiFi AX2 will flash. When this happens, press the HUAWEI
WiFi AX2's WPS/RESET button. The indicator should flash quickly, indicating
that the pairable device is connecting to the HUAWEI WiFi AX2. The
connection process is complete when the indicator stops flashing.
If you touched the WPS/RESET button by accident, wait for 8 seconds till the
indicator returns to normal.
6

Huawei WIFI AX2 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	1201 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Antennas quantity	4
Internal memory	128 MB
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Output current	1 A
Power source type	AC, DC
Power consumption (typical)	12 W
Security algorithms	SSID, WPA3
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product type	Tabletop router
Product color	White
Ethernet LAN (RJ-45) ports	3
Mobile network generation	-

Weight and Dimensions

Depth	163.5 mm
Width	257.6 mm
Height	29 mm
Weight	216 g
