Huazheng CS2670A User Manual

22
When the test is failed, the indicator will light.
12、Test indicator
When the start key is pressed, the indicator will light.
13、Voltage display
14、14、Current display
15、Time display
Time is range from 0.0s to 999s. When the test time is less than 100s, the resolution is
0.1s; while the time is greater than or equal to 100s, the resolution is 1s. If the time is set
to 0.0s, the test time will add counts; when the time is not set to 0, the time will be down
counting.
16、UP key
When do the test time set, press the up key, the test time set will be up.
17、DOWN key
When do the test time set, press the down key, the test time set will be down.
18、Current preset adjustment potentiometer
After pressing the numbered (18) button "test / Pre-set”, the tester will enter into the
current preset state, the current display will show the preset current value, clockwise to
increase the preset current; counterclockwise to decrease the preset current.
19、Test /pre-set key
This key is pressed for the pre-set current state, while pop-up for test status.
20、2mA/20mA switch gear
Press the key is for 20mA gear, pop-up for 2mA gear.
22、AC/DC switch key
Press the key is for DCW test, pop-up for ACW test.
⑧CS2673X front panel outline
