HuddleCamHD 3X - Technical Specifications; Camera & Lens Specs; Pan;Tilt Movement Specs; Connectors, Electrical & Physical Specs

Ver 1.2 7/15
Specs……………………………………………………………………………………………..
Model Number: HC3X-(xx)-G2
Color (xx): WH=White; BK=Black; SV=Silver
Camera & Lens
 Video CMOS Sensor 1/2.7” CMOS, 2.1 Mega Pixel
 Frame Rate 30fps 1920 x 1080p
 Lens Zoom 3X Optical Zoom f = 3-10mm; F = 1.4
 Min Lux 0.5 Lux at F2.0
 Horizontal Field of View 36° (tele) to 81° (wide)
 Warranty 2 Years parts and labor
Pan/Tilt Movement
 Pan Movement ±360°
 Tilt Rotation Up: 90°, Down: 45°
 Presets 64 Presets
Rear Board Connectors
 Video Interface USB 2.0
 Control Signal Interface Mini DIN-8 (VISCA IN, VISCA OUT/RS485)
 Control Signal Config. Dip-Switch Pin 7/TTL Signal
 Baud Rate 9600 bps
 Power Supply Interface DC 12V 2A
Electrical Index
 Power Supply Adapter 12V DC 2A
 Input Voltage 12V DC (10.5-14V DC)
 Input Power 24W (Max)
 Working Environment Indoor
Physical
 Material Aluminum, Plastic
 Dimensions 4.88”W x 5.5”H x 4.75”D [6”H w/ Tilt Up]
(124mm x 139mm x 120mm [152mmH w/ Tilt Up])
 Weight 1.66 lbs (0.75 kg)
 Box Dimensions 8.75” x 8.88” x 7” (222mm x 225mm x 178mm)
 Boxed Weight 3.66 lbs (1.66 kg)
 Color Black, White, *Silver (*Special Order)
 Operating Temperature 32°F to + 113°F (0°C to +45°C)
 Storage Temperature -14°F to 140°F (-10°C +60°C)
 Working Environment Indoor only
