SW2: Used for communication settings.
SW2 DIP-1,2,3: Baud Rate, Communication Protocol
SW2 DIP-4,5: IR Remote Control Receiving Address Table
IR Remote Address
SW2 Switch State (4-5)
DIP-4
DIP-5
0
OFF (Def)
OFF (Def)
1
OFF
ON
2
ON
OFF
3
ON
ON
SW2 DIP-6: IR Output
IR Out
SW2 DIP-6
Disabled
OFF (Def)
Enabled
ON
Baud Rate
SW2 DIP-
1
Communication
Mode
SW2 DIP-
2
Communication
Protocol
SW2 DIP-
3
9600bps
OFF
(Def)
RS-232
OFF
(Def)
VISCA
OFF
(Def)
38400bps
ON
RS-485
ON
PELCO-D
ON
