HuddleCamHD HC-JOY-G2 User Manual

Rev 1.0 8/16
Key Product Features
 All Metal housing.
 VISCA, PELCO-D and PELCO-P protocol support.
 Large LCD Menu display.
 Key-press “BEEP” confirmation (optional – set on or off).
 Pan, tilt, zoom, iris and focus control.
 Variable speed control of pan, tilt and zoom.
 Auto/Manual Focus and Iris.
 Backlight Compensation control.
 Cameras #1-4 ‘Quick Key’ Select buttons.
 Preset Save, Call and Clear.
 Real time display of the current status.
 Short circuit and overcurrent protection.
 Automatic recovery program for the communication port(s).
Key Technical Specifications
 Control Interfaces:
RS232 full-duplex, RS485 semi duplex, RS422 full-duplex.
 Variable Baud Rate 1200 to 19200 bps.
 Maximum communication distance: RS485: 3,937ft [1200m] using 24
gauge twisted pair cabling
 Can control a maximum 255 cameras.
 Voltage: 12VDC.
 Power Consumption: 6W Max.
 Display: LCD.
 Working Temperature: 14°F ~ 122°F [-10° ~ +50° C].
 Working Humidity: 10 ~ 90% (non-condensation).
 Weight 3.4 lbs. [1.6 kg]
 Dimensions: 12.6”(W) x 7.1”(D) x 4.3”(H) [320mm x 181mm x 110mm].
