Hudson 1938 Terraplane User Manual

Front Axle
Toe-in 0 to 1/4"
Caster 1° to 2"
Camber 1° to 1½º
Brakes
Type 4-Wheel Hydraulic
Size 10 1/16" x 1 3/4"
Clearance Between Lining and Drum .010"
Clearance for Mechanical Follow-up 1 7/16"
Steering Gear
Type Variable Pitch Worm and Roller Tooth
Gear Reduction 18.2 to 1
Lubricant Summer and Winter, S.A.E. 90 E.P.
Tires
Size—Standard 16 x 6.00
Size—Optional 15 x 7.00
Air Pressure-16 x 6.00 Front, 24; Rear, 32
Air Pressure-15 x 7.00 Front, 22; Rear, 28
Wheel Jack Bumper Type
Chassis Dimensions
Wheelbase 117"
Tread Front, 56"; Rear, 591/2"
Road Clearance (Center) . Front Axle, 8 9/16"; Rear Axle, 8 7/16"
Over-all Length, including Bumpers—
Brougham 197¾"
Coupe 197¾"
Sedan 197¾"-204¾"
Over-all Width, including Fenders—
Front 71"
Rear 72"
O W N E R' S M A N U A L 11
Capacities
U. S. Imperial Metric
Gasoline Tank
Cooling System
Engine Crankcase
Engine Crankcase (refill)
Clutch
Transmission
Rear Axle
16½ Gals.
12¼ Qts.
6 Qts.
5 Qts.
1/3 Pt.
3 Lbs.
2¾ Lbs.
1¾ Gals.
10¼ Qts.
5 Qts.
4¼ Qts.
1/3 Pt.
3 Lbs.
2¾ Lbs.
62½ Liters
11¾ Liters
5¼ Liters
4¼ Liters
180 cc
1.36 Kgs.
1.24 Kgs.
