Figure 3—Steering Knuckle Pin and Spindle
Assembly Sequence
Figure 3—Revision to Tool J-1374 or J-5566
40 FRONT SUSPENSION—STEERING
FRONT WHEEL ALIGNMENT
SPECIFICATIONS
Turning Angle Inside
Wheel Outside Wheel 25°
20-1/4° L/PS
21-3/4° W/PS
Kingpin Angle 61/2°
Caster Angle Without
Power Steering
0° to 1/2°
1/2° Desired
Caster Angle With Power
Steering
1/2° to 1°
1° Desired
Camber 1/4° Neg. to 1/4° Pos.
0° Desired
Toe-in 1/6" to 3/16"
