Huffy 540D User Manual

10
ID# 21198805 10/05
5.
11
11
1
11
15
10
10
14
XPS01.EPS
211210
18
24
22
8
19
6.
Secure non-secured ends of tank struts (11) to
tank as shown. Repeat for opposite side.
Attach extension arm (18) to pole using
U-bolt (22), washers (19), nuts (8), as shown. Install pole cap (24) as shown.
DO NOT LEAVE ASSEMBLY
UNATTENDED WHEN
EMPTY; IT MAY TIP OVER.
WARNING!
