Install wheel axle (2) through wheel carriage (7) and install wheels (3) onto
wheel axle (2) with spacers (26) as shown. Insert pole assembly into tank
assembly as shown. Secure bottom pole (4) to tank and wheel bracket as
shown, a deep socket is recommended. IMPORTANT! DO NOT OVER
TIGHTEN.
Secure tank struts (11) to pole.
Rotate non-secured ends of tank
struts (11) outward to mounting
holes in tank as shown.
TWO PEOPLE REQUIRED
FOR THIS PROCEDURE.
FAILURE TO FOLLOW THIS
WARNING COULD RESULT IN
SERIOUS INJURY AND/OR
PROPERTY DAMAGE.
WARNING!
THE SPACER (26) WILL
FIT LOOSELY UNTIL
SECURED INTO THE
CAVITY OF THE BASE.
IMPORTANT!:
TIGHTEN BOLT (9) IN
LOCK NUT (12) UNTIL
FLUSH (EVEN) WITH LOCK
NUT’S OUTER EDGE.
