3
ASSEMBLY INSTRUCTIONS
Note: Clamp (2) may be pre installed from factory on Handlebar Post (3) and may
need to be loosened before assembly.
1. Make sure the Front Wheel (1) and Lock Button (A) are facing forward as shown.
2. Place Clamp (2) onto Handlebar Post (3) so that Clamp is even with bottom of
Handlebar Post (View B) and Slot (C) is facing forward.
3. Slide Handlebar and Clamp onto Threaded Steering Tube (4) until Lock Button
(A) snaps into top of Cutout Slot (C).
4. Tighten Clamp Screws (5) evenly and securely so that the Handlebar does not
move.
4
A
1
2
A
5
B
C
3
To Next Page
