Humanscale M10 - Mounting to Work Surface; Clamp Mount Installation; Bolt-Through Mount Installation; Sliding Desk Mount Installation

2
①
④
⑦
⑨
⑩ ⑪
⑧
②
⑤
③
⑥
Bolt-Through Plate
3 Crossbar Link Screws4mm Hex Key
8 mm Hex Key Bolt-Through Bolts
Bolt-Through Mount
Sliding Desk Mount Clamp Mount
Crossbar Installation Hardware
4 Standard VESA Bracket
Screws
4 Plastic Spacers
4 Extended VESA Bracket
Screws
VESA Bracket and Cover
5mm Hex Key
NOTE: 4mm and 5mm Hex Key can
be found under the plastic base cover.
INSTALLATION HARDWARE
⑫
⑬
