Parking the plug
Fig. 11 Securing the plug
1 Locking nubs
2 Cliplock
3 Plug
After uncoupling the trailer, insert the
plugs into the respective parking
sockets (Fig. 11/3).
Twist the cliplock (Fig. 11/2) onto the
locking nubs (Fig. 11/1) on the parking
socket.
The plugs are firmly seated in the parking
socket in the park console.
Fig. 12 Plug, parked
1 Parking socket / cap
2 Cliplock
3 Park console
Parked plug connections are protected
from damage/contamination.
Maintain the contacts of the plug
connections with contact spray, if
necessary.
Clean dirty plug connections before
departing.
Have defective, torn, worn plug
connections replaced immediately in
an approved workshop.
