Screw parking brake
78
Operation: chassis
4
Releasing
Fig. 15 Releasing the screw parking brake
1 Crank
Release the hook (Fig. 14/2) from the
crank (Fig. 15/1).
Rotate the crank (Fig. 15/1).
Rotate the crank (Fig. 15/1)
anticlockwise as far as it will go.
The trailer is unbraked.
Securing in the drive position
Fig. 16 Screw parking brake secured
1 Crank
2 Securing cable with hook
Fit the hook of the securing cable
(Fig. 16/2Fig. 161) over the crank.
The screw parking brake is secured
against turning of its own accord.
WARNING
Driving with unsecured crank
The crank may be ripped off during
driving - risk of striking!
Check before driving that the crank is
secured with the securing cable.
1
1
2
