3. PRODUCT OVERVIEW
3.4 COMPONENTS
2x INTERCEPTOR
2x INTERCEPTOR BRACKET
2x CABLE COVER
CONTROL UNIT
CONTROL PANEL CABLE
CONTROL PANEL CABLE
NMEA DROP CABLE
CHINE ONLY:
2x INTERCEPTOR BRACKET ADD-ON
DRILL TEMPLATES
• Interceptor Drill Template
INCLUDED SCREWS
Component
Amount Size Part Number Bits (not included)
Control Panel 4 2.9x13 mm 040284 PH1
Control Unit 4 4.2x25 mm 023740 T20
2x16 6.3x32 mm 023597 T30
Interceptor 2x2 M8x75 mm 011239 6 mm
Cable Cover 2x11 3.5x12 mm 023691 T15
NOTE!
• Control Unit & Control Panel
Drill Template
