41780-01 4
Description of Air Filtration System
Air Purier Components
Fig. 1 - Illustration of the Air Filtration System
Fig. 2 - Air Purier Components
HEPAtech
®
FILTER
PREFILTER
FRONT
GRILL
BASE
How the HEPAtech
®
Plus Air Purier System Works
As the air is pulled into the purier, the activated carbon pre-lter absorbs odors and catches
large particles. Then, the air travels through the HEPAtech
®
lter where the smaller particles
are collected. Then, the ionizer releases negative ions into the air that attract positively
charged dust, smoke, and pollen particles. Finally, the clean, puried air is released back
into the room.
Dust & Irritants
Pollen & Allergens Odors Bacteria Pet Hair & Dander
Carbon
Pre-lter
HEPAtech
®
Filter
99.97% – .1 Microns
Ionizer
