14ga YELLOW/RED (MEMORY, NEEDS CONSTANT HOT TO RETAIN)
14ga RED/YELLOW
14ga YELLOW
TO DC PANEL
(ANT. LOCATED BEHIND STEREO)
DEALER SUPPLIED CABLES
CONSULT MANUF. OWNERS MANUAL FOR DETAILS
ANT.
OPT. CD
PLAYER/
RADIO
PORT SPEAKER WHITE/RED 16ga.
STBD SPEAKER WHITE/BROWN 16ga.
GROUND WHITE/YELLOW 16ga.
GROUND WHITE/BLACK 16ga.
10A
(10AMP FUSE ON RADIO)
+
+
64E-4
FWD SPEAKERS OUTPUT
AFT SPEAKERS
CONNECTED TO BILGE
RESET CIRCUIT
GROUND WHITE/BLACK 16ga.
STBD SPEAKER WHITE/VIOLET 16ga.
GROUND WHITE/YELLOW 16ga.
PORT SPEAKER WHITE/GREEN 16ga.
AFT STEREO FWD STEREO
FWD SPEAKERS OUTPUT
OUTPUT(NOT USED)
OUTPUT(NOT USED)
AFT SPEAKERS
DIFFERENCE IS THE COLOR OF THE POSITIVE SPEAKER LEAD.
THE FWD AND THE AFT STEREOS ARE WIRED THE SAME. THE ONLY
NOTE:
