(ANT. LOCATED BEHIND STEREO)
DEALER SUPPLIED CABLES
CONSULT MANUF. OWNERS MANUAL FOR DETAILS
ANT.
OPT. CD
PLAYER/
RADIO
PORT SPEAKER WHITE/PINK 16ga.
STBD SPEAKER WHITE/GRAY 16ga.
GROUND WHITE/YELLOW 16ga.
GROUND WHITE/BLACK 16ga.
(10AMP FUSE ON RADIO)
64E-8
-
+
TO COURTESY LIGHT BREAKER
TO NEGATIVE BUS
16ga BLUE/WHITE
16ga YELLOW
FWD SPEAKERS OUTPUT
AFT SPEAKERS OUTPUT(NOT USED)
12ga ORANGE/GREEN (MEMORY, NEEDS CONSTANT HOT TO RETAIN)
TO DC PANEL
RESET CIRCUIT
CONNECTED TO BILGE
+
10A
12ga YLW
12ga RED
COCKPIT STEREO HARNESS
ARCH HARNESS
CONNECTION E.
ARCH CONNECTION
