Wiring
F
R
O
M
F
A
N
F
R
O
M
C
E
I
L
I
N
G
B
R
A
C
K
E
T
F
R
O
M
F
A
N
Using an orange wire
connector from the
hardware bag, connect the
3 grounding wires (green,
green/yellow stripe, or
bare copper) coming from
the ceiling, downrod, and
hanging bracket.
(Grounding)
Green/Yellow
Stripe
Green/Yellow
Stripe
White
Black
(Grounded)
Note: To connect the wires, hold the bare metal
leads together and place a wire connector over
them, then twist clockwise until tight.
Using the orange wire
connectors from the
hardware bag, connect the
black wire (ungrounded) from
the ceiling to the black and
the black with white stripe
wires from the fan. Connect
the white wire (grounded)
from the ceiling to the white
wire from the fan.
Black with
white stripe
F
R
O
M
C
E
I
L
I
N
G
F
R
O
M
C
E
I
L
I
N
G
Turn the splices upward and push them carefully back through the hanger bracket
into the outlet box. Spread the wires apart, with the grounded wires on one side of
the outlet box and the ungrounded wires on the other side of the outlet box.
Refer to CAUTION c.1 on pg. 2
(Ungrounded)
9
MB529-01 • 11/15/16 • © 2016 Hunter Fan Company
