ACC2 STRONGBOX PEDESTAL ASSEMBLY INSTRUCTIONS
Assembly
Reassembling the Hunter ACC2 inner
chassis assembly: Output module
(Decoder version shown)
Step 1: Make sure the slidelock is in the
UNLOCKED position (slide to the right).
Install the output module into the deck
assembly (Fig. 1).
Step 1: Slide the slidelock to the le to the
LOCKED position (Fig. 2).
Fig. 1 Fig. 2
○
