7
8
Reverse
Switch
Ceiling fans work in two directions: downdraft (counterclockwise rotation) and updraft (clockwise
rotation). To change the direction of air ow, turn the fan off and let it come to a complete stop.
The reversing switch is located on the side of the fan. Slide the reversing switch to the opposite
position. Restart the fan.
Updraft (clockwise rotation)
creates a more indirect airow.
Updraft airow is great for
moving warm air downward.
Downdraft (counterclockwise
rotation) creates a direct breeze
and maximum cooling effect.
Repeat x2
Feed the pull chains from the fan switch
and the light switch down through the
holes in the upper switch housing as
shown. Attach the pull chain pendants
to the light and fan pull chains.
The fan pull chain controls
the speed: from high to off.
The light pull chain controls
the light xture: on and off.
Installing the Pull Chains
Fan style may vary.
Note:
Fan style may vary.
Note:
