Install the wiring cover plate. Make sure all
wiring connections are inside the box or under
the wiring cover plate.
Tighten the wiring cover plate screw.
Reinstall the motor by inserting the tabs and pushing up into
position. Make sure the wires are not pinched
between the motor and the housing.
Secure the motor by tightening the 2 screws.
Connect 4” duct and vent to the outside. Tape joints.
to be purchased.
Connect wiring from the motor to the wiring cover plate.
