2
Do not discard the hardware bags or mix parts from
different bags. Make note of the symbol printed on
each hardware bag. The symbols can be used to
identify the appropriate hardware for each step.
x4
x4
x4
x15 x15
x2
x2
x2
For installing the hanger bracket and wiring the fan
For installing the blades
For installing the canopy
For installing the light xture
Hunter Pro Tip:
Find a part that is missing or damaged?
Don’t take it back to the store. Let us make it right. Visit us at HunterFan.com or call us at 1.888.830.1326.
Spare Parts
For your convenience,
you may receive extra fasteners. Pullchains and extra downrod
Bulb
Glass
Lower Switch Housing
Upper Switch Housing
Blade Arm
Blade
Canopy
Downrod
Motor
Canopy Screw
Blade Screw
Grommet
Ceiling Bracket
Wood Screw
WIre Nut
Washer
x6
Light Kit Screw
Fan style may vary.
Note:
M0263-01 r101320
x5
x5
We recommend that you pull everything out of the box and lay it out. We have
grouped the drawn components below with the hardware you’ll need for those
parts. The screws below are drawn to scale to make it easier to identify what
piece of hardware is needed to install each component.
Here is what comes in your box:
D
I
S
C
A
R
D
K
E
E
P
Remove the ORANGE shipping
ring from the motor. Save the
screws. They will be needed for
blade iron installation.
Blade Arm Screw
x5
To Next Page
