110V.A.C. (220 OVERSEAS MODELS) DISTRIBUTION PANEL
BREAKER
DESCRIPTION
"A" SIDE OF A.C. PANE
A.C. MAIN PROVIDES A.C. VOLTAGE TO THIS SIDE OF PANEL WHEN SHORE POWER CORD "A" IS CONNECTED TO OUTLET AT
DOCKSIDE POWER SUPPLY.
OUTLETS PROVIDES A.C. POWER TO THE BOAT'S OUTLETS
MICROWAVE SUPPLIES POWER TO OUTLET BEHIND MICROWAVE IN WHICH MICROWAVE IS PLUGGED INTO.
BATT. CHARGER PROVIDES POWER TO BATTERY CHARGER WHICH IN TURN PROVIDES CHARGING POWER TO BATTERIES. NOTE:
IF OPTIONAL INVERTER CHOSEN THIS BREAKER IS NOT UTILIZED AND IS AVAILABLE AS A "SPARE" BREAKER. *SEE BELOW
WATER HEATER
SUPPLIES POWER TO WATER HEATER. BE SURE TANK IS FULL AND SYSTEM IS FREE FROM AIR BEFORE
APPLYING POWER TO HEATER TO PREVENT ELEMENT BURNOUT. NOTE DO NOT TRY TO POWER WATER HEATER
OFF OF THE OPTIONAL INVERTER, IT IS NOT CAPABLE OF SUPPLYING ENOUGH POWER TO POWER UNIT.
MISC. INFO
SPARE BREAKERS *SEE BELOW
LED INDICATORS ILLUMINATE WHEN A.C. POWER PRESENT.
METER GAUGE ALLOWS VOLTAGE BEING SUPPLIED TO BE DISPLAYED
REV. POLARITY IF REVERSED POLARITY INDICATOR ILLUMINATES AFTER CONNECTING SHORE POWER HAVE DOCKSIDE POWER
CHECKED BY QUALIFIED PERSONELL.
NOTE: SEE PAGE 64B-1 FOR BREAKER AMPERAGES
SPARE BREAKERS BE AWARE OF THE SPARE BREAKER'S AMPERAGE TO BE SURE THAT IT IS COMPATABLE WITH ANY DEVICE
CONNECTED TO THESE BREAKERS (ADDITIONAL "SPARE BREAKER" LOCATIONS PROVIDED ONLY)
NOTE: A PRUDENT MARINER REALIZES THAT THE RESOURCES TO POWER A VESSEL ARE
LIMITED. WHEN USING THE BATTERY CHARGER OR INVERTER ONE SHOULD BE CONSERVATIV
AND AWARE OF THE AMOUNT OF POWER BEING SUPPLIED VERSES POWER BEING DRAW
THIS IS ESPECIALLY IMPORTANT WHEN USING OPTIONAL INVERTER POWER. CONSULT THE
"INVERTER MANUAL" FOR POWER OUTPUT CAPABILITIES
PAGE 63A-6
