Hunter H356 - Page 140

MASTER ELECTRICAL WIRING/CABLE DATA
DESCRIPTION PRT. NUMBER WIRE SIZE WIRE COLOR
LPG SWITCH/POWER 659802 16 gauge ORANGE/RED
TANK DISPLAY 658600 16 gauge RED/BLUE
FUEL SENDER 658100 16 gauge PINK,ORANGE/WHITE
GROUND 659800 16 gauge YELLOW
FWD WATER SENDER 659806 16 gauge ORANGE/BLUE, PINK/BLACK
GROUND 659800 16 gauge YELLOW
WATER PUMP 655200 12 gauge BROWN
GROUND 659700 12 gauge YELLOW
VACCU FLUSH 652202 10 gauge BROWN/RED
GROUND 659800 16 gauge YELLOW
AFT WASTE SENDER 659805 16 gauge ORANGE/GREEN, PINK/GRAY
GROUND 659800 16 gauge YELLOW
AFT SUMP PUMP 655400 12 gauge BROWN/BLACK
GROUND 659700 12 gauge YELLOW
FWD MACERATOR 655800 10 gauge BROWN/WHITE
GROUND 659800 16 gauge YELLOW
SOLAR PANEL 653640 16/2 DUPLEX RED/YELLOW
VHF 653300 16 gauge RED/WHITE
GROUND 659800 16 gauge YELLOW
COURTESY LIGHTS 655100 16 gauge BLUE/WHITE
GROUND 659800 16 gauge YELLOW
CABIN LIGHTS 655000 16 gauge BLUE
GROUND 659800 16 gauge YELLOW
PORT FWD SPEAKERS 653620 16 gauge WHITE/RED
STBD FWD SPEAKERS 653622 16 gauge WHITE/BROWN
PORT MAIN SPEAKERS 653623 16 gauge WHITE/ORANGE
STBD MAIN SPEAKERS 653624 16 gauge WHITE/BLUE
PORT AFT SPEAKER 653625 16 gauge WHITE/GREEN
STBD AFT SPEAKER 653626 16 gauge WHITE/VIOLET
PORT ARCH SPEAKER 653627 16 gauge WHITE/PINK
PORT GROUND 653629 16 gauge WHITE/YELLOW
STBD ARCH SPEAKER 653630 16 gauge WHITE/GRAY
STBD GROUND 659800 16 gauge WHITE/BLACK
COMPASS BOW LIGHT 659804 16 gauge GRAY/WHITE
STERN LIGHT 16 gauge GRAY/YELLOW
GROUND 659800 16 gauge YELLOW
MAST LIGHT 657300 16 gauge GRAY
STEAMING LIGHT 656800 16 gauge GRAY/GREEN
ANCHOR LIGHT 656900 16 gauge GRAY/RED
HOUSE BATTERY 653610 2/O, 2 gauge RED
GROUND 653900 2/O, 2 gauge YELLOW
AC/DC PANEL 657900 6 gauge ORANGE/RED,ORANGE/GREEN
GROUND 653618 6 gauge YELLOW
ENGINE 654100 1/O, 2 gauge RED
HALYARD 654010 1/O, 2 gauge YELLOW
T.V. / V.C.R. 658400 10 gauge RED
GROUND 653631 10 gauge YELLOW
REFRIGERATION 658800 8 gauge RED/BLACK
FREEZER 658900 8 gauge RED/WHITE
GROUND 653615 8 gauge YELLOW
STEREO OUT 657600 12 gauge ORANGE/GREEN
STEREO POWER 658500 12 gauge RED
GROUND 659700 12 gauge YELLOW
INVERTER GROUND 653642 4 gauge GREEN/YELLOW
WINDLASS SWITCH 659200 16 gauge TAN
MANUAL BILGE 655700 12 gauge BROWN/RED
AUTO BILGE 655600 12 gauge BROWN/ORANGE
GROUND 659700 12 gauge YELLOW
AFT MACERATOR 652400 10 gauge BROWN
AFT SUMP PUMP 655400 12 gauge BROWN/BLACK
FWD SUMP PUMP 654600 12 gauge BROWN/YELLOW
AUTO PILOT 658700 10 gauge RED
GROUND 653615 10 gauge YELLOW
CHAINPLATE 653642 4 gauge GREEN/YELLOW
BATTERY CHARGER # 1 658000 8 gauge ORANGE/RED
BATTERY CHARGER # 2 657800 8 gauge ORANGE/GREEN
NOT ALL FEATURES APPLY TO ALL BOAT MODELS
PAGE 65A-2
